Furnace Lining Kiln Aluminum Silicate Heat Resistant Board 20mm 50mm 1430 Degrees Ceramic Fiber Inorganic Insulating Boards

Brand Name : RONGSHENG

Certification : ISO9001

Place of Origin : Henan, China

MOQ : 1 Ton

Pack : Powder: bag, liquid: barrel

Water Absorption : 0.3% max

Bulk Density Dried : 70-100kg/m3

Porosity : Low

Compressive Strength : 100-500 MPa

Relative Density : 1.44~1.47

Shapes : Available in various shapes and sizes

Cao Min : 33

Shape : Brick, Tile, Fiber, etc.

Bulk Density : 0.5

Tensile Strength : 0.04MPa

Corrosion Resistance : High

Bulk Dentisy Min : 2.4

Color : black

Origin : Xinmi

Contact Now

Ceramic fiber board is a high-performance insulating product formed by ceramic fiber and adhesive in vacuum. It is flat, ceramic materials are evenly distributed, and has excellent heat insulation performance. Due to its low thermal conductivity and low heat storage, no inflation during heating can reduce energy cost and cycle time, and protect the refractory surface from thermal shock and chemical attack. Therefore, it is an ideal product for fire resistance, heat insulation and heat insulation.

Features

1.Low heat storage;
2.Resistant to Non-Ferrous Metals;
3.Excellent resistance to thermal shock and chemical attack;
4.Resists oxidation and reduction;
5.High mechanical strength at high temperature;
6.Can be machined, cut and shaped easily
7.High rigidity and light weight

Furnace Lining Kiln Aluminum Silicate Heat Resistant Board 20mm 50mm 1430 Degrees Ceramic Fiber Inorganic Insulating Boards

Specification
Standard ceramic fiber blanket - working temperature 1050 ℃
High-alumina ceramic fiber blanket - working temperature 1260 ℃
Zirconia ceramic fiber blanket - working temperature 1350 ℃
Thickness 6-50mm
Type COM ST HP HA Zir-Alu HZ
Classified Temp. 1100ºC
(1983ºF)		 1260ºC
(2300ºF)		 1260ºC
(2300ºF)		 1360ºC
(2480ºF)		 1400ºC
(2550ºF)		 1430ºC
(2600ºF)
Working Temp. <1000ºC
(2012ºF)		 1050ºC
(1922ºF)		 1100ºC
(2012ºF)		 1200ºC
(2192ºF)		 1200ºC
(1192ºF)		 1350ºC
(2462ºF)
Color white white white white white white
Density(kg/m3) 260-320
(16-20lb/ft3)
Linear Shrinkage (%)(24 hrs) -3 (1000ºC/1832ºF)
Thermal conductivity(W/M.K) 0.085 (400ºC/752ºF)
0.132 (800ºC/1472ºF)
0.180 (1000ºC/2012ºF)
Compression Strength(Mpa) 0.5 0.5 0.5 0.5 0.5 0.5
Chemical(%) Al2O3 44 46 47-49 52-55 45-46 39-40

Al2O3

+SiO2

 96 97 99 99 - -

Al2O3

+SiO2

+ZrO2

 - - - - - 99
ZrO2 - - - - 5-7 15-17
Fe2O3 <1.2 <1.0 0.2 0.2 0.2 0.2

Na2O

+K2O

 ≤0.5 ≤0.5 0.2 0.2 0.2 0.2
Size(mm) 1200*1000mm(47″*40″); 1000*600mm(40″*36″);900*600mm(24″*36″)
20-50mm(1″/2″)thickness
Advantages

Furnace Lining Kiln Aluminum Silicate Heat Resistant Board 20mm 50mm 1430 Degrees Ceramic Fiber Inorganic Insulating Boards
